Tamiya Knight Hauler
About the Tractor Truck Knight Hauler This 1/14 scale R/C Tractor Trucks Item features an originally designed truck body. Hood, large roof spoiler, interior, and lights (clear orange parts), which have been artistically rendered in exquisite detail. Grill, tank, exhaust and steps have been beautifully rendered with metal plated parts. Kit includes stickers and 540 motor. 7.2V battery pack and R/C system are sold separately.
Using the left stick, you can switch gears on the fly. While pushing forward move stick left (low), Middle (med) or right (high). You can also start off in one of those speeds by being in that position before pressing forward.
Specs and Features
- Total length: 630mm
- Total width: 186mm
- Clearance: 19mm
- Weight Fully-Equipped: about 3,1kg (without multi function unit)
- Wheelbase: 476mm
- Tread F/R: 156/138mm
- Tire Width: F/R both 22mm
- Tire Diameter: F/R both 88mm
- Chassis Material: Aluminum and polycarbonate plastic
- Chassis Shape: Ladder Type Frame
- Suspension: Front and Rear Rigid Axle w/Metal Leaf Springs
- Caster Angle-F/R: 0deg/0deg
- Camber Angle-F/R: 0deg/0deg
- Toe Angle-F/R: 0deg/0deg
- Damper: F/R Aluminum Dummy Dampers
- Drive train: 2-axle
- Transmission: 3-gear transmission (gear shifting operated via transmitter)
- Gear Ratio: 1st gear 32.49:1, 2nd gear 17.76:1, 3rd gear 10.66:1
- Diff. gear system: F/R Bevel Gear Diff
- Engine: Electric 540
- Body Type: Styrene(plastic)
Required:
- 4-channel system is recommended for potential future options and 3-speed operation.
- 7.2V battery and charger
- ESC (unless you are using MFC Unit #56511)
