Carson ESC
Carson Dragster ESC Electronic Speed Controller Brushed 70A
Equipped with a Deans style connector and a Deans style to Tamiya adaptor lead. Suitable for most brushed motor applications.
These ESCs are coded 500906264 on the ESC themselves but 500906268 on the bag they are supplied in.
Specification Forward: Continues/Peak current 70A/360A Backward: Continues/Peak current 40A/180A Battery type: 2-3s Li-Po, 5-9 cells NiMH Type of Model: 1:10 / 1:12 / 1/16 – ON Road, OFF Road, Boat 2s Lipo or 6 cells NimH: 540, 550 motor lowest 18 turn with 30000 rpm @ 7.2v BEC Output Voltage: 3A/6v Size: 34.5mm x 30.2mm x 18.7mm Weight: 39g Mode: Boat, Forward/Backward, Crawler
